Product Overview
The Ion Endeavor is a pump controller that senses a water level of up to 72", has a configurable water level/pump turn-on setting, the ability to run two pumps simultaneously, pump alternation, pump failure sensing, local audible/visual alarm notification, local alarm silencing, and remote alarm notification.
Features
- Ion® digital level sensors.
- First of its kind solid-state sensing technology with no moving parts.
- Multipoint sealing mechanism that supersedes single surface seals.
- Simultaneously operates two (2) single-phase plug in pumps together when required.
- Automatic pump alternation based on duty cycle and/or pump availability.
- Clean & safe operation.
- Microprocessor based process controls continually monitor system.
- Dry digital contact for common alarm, allows remote monitoring.
- 200-240VAC standard plug in receptacle.
- Dual pump run and alternating controller for residential and commercial applications.
- Ion sensors communicate with controller to provide controller-based turn on level adjustment from 2.5" to 72" for optimal pump operation.
- Track critical information through the panel-based display, including switch failure, pump amp draw, water level, and more.
System Specification
- Voltage: 120 VAC
- Maximum Output: 16 Amps (20 Amp breaker)
- Remote Alarm Contacts: Normally Closed, 30 VAC/DC @ 1 Amp
- Temperature Range: -20 °C to 60 °C (-4 °F to 140 °F)
- Audible Alarm: > 90 dB at 2 feet
- Enclosure: NEMA-1 Polycarbonate
- Dimensions:
- Controller: 8” x 6” x 4”
- Sensors: 4.62” x 4.62”
- Mounting Straps: 5.25” x 3.50”
- Mounting: Up to #10 screws
